MSU Video Codecs Comparison 2022
Part 5: FullHD 10-bit

Seventeen Annual Video-Codecs Comparison by MSU

Video group head: Dr. Dmitriy Vatolin
Project head: Dr. Dmitriy Kulikov
Measurements, analysis: Nickolay Safonov,
Ekaterina Shumitskaya
Nikita Alutis,
Mikhail Voronin,
compression.ru Lomonosov
Moscow State University (MSU)
Graphics and Media Lab
Dubna International
State University
Institute for Information
Transmission Problems,
Russian Academy of Science

News

  • 25.09.2023 Release of the comparison

Navigation


Results


  • The places below are given only for quality scores, not taking encoding speed into account
  • Encoders with scores closer than 1% share one place
Slow (1 fps) Medium (5 fps) Fast (30 fps)
Best quality
(YUV-SSIM 6:1:1)
1st: Ali266 (H.266),
Tencent266 v0.2.1 (H.266),
Tencent266 v0.2.2 (H.266)
2nd: Tencent TVC encoder (Private)
3rd: BILIVVC (H.266)
1st: Tencent266 v0.2.2 (H.266), Tencent266 v0.2.1 (H.266)
2nd: Tencent TVC encoder (private), BILIVVC (H.266)
3rd: Tencent TXAV1 encoder (AV1)
1st: Tencent266 v0.2.2 (H.266), Tencent266 v0.2.1 (H.266)
2nd: Tencent TXAV1 encoder (AV1)
3rd: SVT-AV1 (AV1), Tencent V265 encoder (H.265)
Best quality
(YUV-PSNR avg.MSE 6:1:1)
1st: Tencent266 v0.2.1 (H.266),
Ali266 (H.266)
2nd: Tencent266 v0.2.2 (H.266)
3rd: Tencent TVC encoder (private)
1st: Tencent266 v0.2.1 (H.266)
2nd: Tencent266 v0.2.2 (H.266), Tencent TVC encoder (private), BILIVVC (H.266)
3rd: Tencent TXAV1 encoder (AV1)
1st: Tencent266 v0.2.1 (H.266)
2nd: Tencent266 v0.2.2 (H.266)
3rd: Tencent TXAV1 encoder (AV1)
Best quality
(YUV-VMAF* 0.6.3 6:1:1)
1st: Tencent TVC encoder (private)
2nd: Tencent TXAV1 encoder (AV1)
3rd: Tencent266 v0.2.1 (H.266)
1st: Tencent TVC encoder (private)
2nd: Tencent TXAV1 encoder (AV1)
3rd: Tencent266 v0.2.1 (H.266)
1st: Tencent TXAV1 encoder (AV1), Tencent V265 encoder (H.265)
2nd: Tencent266 v0.2.1 (H.266)
3rd: Tencent266 v0.2.2 (H.266)
Best quality
(Y-VMAF 0.6.3)
1st: Tencent TVC encoder (private)
2nd: Tencent266 v0.2.2 (H.266)
3rd: Tencent TXAV1 encoder (AV1), Tencent266 v0.2.1 (H.266)
1st: Tencent TVC encoder (private), Tencent266 v0.2.2 (H.266)
2nd: Tencent TXAV1 encoder (AV1), Tencent266 v0.2.1 (H.266)
3rd: Tencent V265 encoder (H.265)
1st: Tencent266 v0.2.2 (H.266)
2nd: Tencent TXAV1 encoder (AV1), Tencent266 v0.2.1 (H.266)
3rd: Tencent V265 encoder (H.265)
Best quality
(Y-VMAF-NEG 0.6.1)
1st: Tencent266 v0.2.2 (H.266)
2nd: Tencent TVC encoder (private)
3rd: Tencent266 v0.2.1 (H.266)
1st: Tencent266 v0.2.2 (H.266)
2nd: Tencent TVC encoder (private), Tencent266 v0.2.1 (H.266)
3rd: Tencent TXAV1 encoder (AV1)
1st: Tencent266 v0.2.2 (H.266)
2nd: Tencent266 v0.2.1 (H.266)
3rd: Tencent TXAV1 encoder (AV1)

* - YUV-VMAF was calculated as VMAF for all colour-planes (Y, U, V) following the same methodology as YUV-SSIM, YUV-PSNR and other metrics.

The biggest number of codecs took part in comparison of Slow encoding (1 fps). The winners vary for different objective quality metrics. The participants were rated using BSQ-rate (enhanced BD-rate) scores [1].


[1] A. Zvezdakova, D. Kulikov, S. Zvezdakov, D. Vatolin, "BSQ-rate: a new approach for video-codec performance comparison and drawbacks of current solutions," 2020.

Download and buy report


Free Enterprise
Number of test sequences 3 13
Test video descriptions
Basic codec info
Objective metrics Only 5 metrics 20+ objective metrics
Test videos download
Encoders presets description
HTML report 55 interactive charts 9000+ interacive charts
Price Free 950 USD
Download/Buy
HTML report (ZIP)
You will receive enterprise versions of all 2022 reports (FullHD, Subjective, 4K)

Participated codecs


Codec name Use cases Standard Version
1 x264 (H.264)
x264 (H.264) project
Slow (1 fps),
Medium (5 fps),
Fast (30 fps)
H.264/AVC r3065-ae03d92, Windows
2 Reference x265 (H.265)
MulticoreWare, Inc.
Slow (1 fps),
Medium (5 fps),
Fast (30 fps)
H.265/HEVC 3.5+1-f0c1022b6, Windows
3 SVT-HEVC (H.265)
Open Visual Cloud
Slow (1 fps),
Medium (5 fps),
Fast (30 fps)
H.265/HEVC 1.5.1, Windows
4 Tencent V265 encoder (H.265)
Tencent
Slow (1 fps),
Medium (5 fps),
Fast (30 fps)
H.265/HEVC 1.6.4, Linux
5 Ali266 (H.266)
Alibaba Group - DAMO Academy
Slow (1 fps) H.266/VVC v1.14, Windows
6 BILIVVC (H.266)
Bilibili Inc.
Slow (1 fps),
Medium (5 fps)
H.266/VVC 1.1.0, Linux
7 Tencent266 v0.2.1 (H.266)
Tencent
Slow (1 fps),
Medium (5 fps),
Fast (30 fps)
H.266/VVC v0.2.1, Linux
8 Tencent266 v0.2.2 (H.266)
Tencent
Slow (1 fps),
Medium (5 fps),
Fast (30 fps)
H.266/VVC v0.2.2, Linux
9 VVenC (H.266)
Fraunhofer HHI
Slow (1 fps),
Medium (5 fps)
H.266/VVC 1.6.1, Linux
10 aom (AV1)
aom (AV1)edia
Slow (1 fps) AV1 aom (AV1)edia Project AV1 Encoder 3.1.0-309-g12287adee, Linux
11 rav1e (AV1)
The rav1e (AV1) contributors
Slow (1 fps),
Medium (5 fps),
Fast (30 fps)
AV1 0.5.0-alpha (p20210518), Windows
12 SVT-AV1 (AV1)
Open Visual Cloud
Slow (1 fps),
Medium (5 fps),
Fast (30 fps)
AV1 v1.3.0, Windows
13 Tencent TXAV1 encoder (AV1)
Tencent
Slow (1 fps),
Medium (5 fps),
Fast (30 fps)
AV1 1.3.5, Linux
14 Tencent TVC encoder (private)
Tencent
Slow (1 fps),
Medium (5 fps)
- 0.1.1, Linux

Comparison Rules


FullHD 10-bit codec testing objectives

The main goal of this report is the presentation of a comparative evaluation of the quality of new and existing codecs using objective measures of assessment. The comparison was done using settings provided by the developers of each codec. Nevertheless, we required all presets to satisfy minimum speed requirement on the particular use case. The main task of the comparison is to analyze different encoders for the task of transcoding video – e.g., compressing video for personal use.

Test Hardware Characteristics

  • CPU: Intel Core i7 12700K (Alder Lake)
  • SSD: 1Tb
  • RAM: 4x16GB (64GB)
  • OS: Windows 11 x64, Ubuntu 22.04 LTS

For this platform we considered three key use cases with different speed requirements:

  • Online – 1080p@30fps
  • Online – 1080p@5fps
  • Offline – 1080p@1fps

See more on Call For Codecs 2022 page

Videos

Videos for testing set were chosen from new MSU video collection 2021via a voting among comparison participants, organizers and an independend expert.

Number of videos in MSU video collection
Year # FullHD videos # FullHD samples # 4K videos # 4K samples Total # of videos Total # of samples
2016 3 7 882 2902 885 2909
2017 1996 4638 1544 4561 3540 9299
2018 4342 10330 1946 5503 6288 15833
2020 4945 12402 2091 6016 7036 18418

Bitrate distribution of videos in MSU video collection Videos bitrate distribution

Final video set consists of 51 sequences including new videos from Vimeo and media.xiph.org derf's collection.


Video sequences selection

Descriptions of all test videos are presented in a separate PDF provided with the report.
